| UPC Code |
886523304746 |
| Case Dimensions |
449 x 234 x 474 mm | 17.67 x 9.21 x 18.66 in |
| Form Factor |
Mid-Tower |
| Mainboard Support |
ATX | Micro-ATX | Mini-ITX |
| Materials |
Steel panels | Tempered glass window | ABS plastic |
| Color |
Black |
| Expansion Slots |
4 (Starting from first slot position) |
| Vertical GPU Support |
No |
| Internal 2.5″ Positions |
1 + 1x 3.5″ HDD |
| Internal 3.5″ Positions |
1 + 1x 2.5″ SSD |
| Front I/O |
2x USB 3.0, 1x USB-C 3.2 Gen2x2, 1x Microphone/Headphone combo, Power button, Reset button |
| Total Fans (120 | 140) |
4 | – |
| Fans – Top (120 | 140) |
– | – |
| Fans – Front (120 | 140) |
– | – |
| Fans – Side (120 | 140) |
3+1 | – |
| Fans – Rear (120 | 140) |
– | – |
| Fans – Bottom (120 | 140) |
– | – |
| Radiator – Top (120 | 140) |
– | – |
| Radiator – Front (120 | 140) |
– | – |
| Radiator – Side (120 | 140) |
Max. 360 | – |
| Radiator – Rear (120 | 140) |
– | – |
| Radiator – Bottom (120 | 140) |
– | – |
| CPU Cooler Height Clearance |
72 mm | 2.83 in |
| GPU Length Clearance |
358 mm | 14.09 in |
| GPU Width Clearance |
175 mm | 6.88 in |
| Power Supply Length Clearance |
210 mm | 8.26 in |
| GPU PCI-slot 1 Thickness |
4.6 Slots / 93 mm | 3.66 in |
| GPU PCI-slot 2 Thickness |
3.6 Slots / 73 mm | 2.87 in |
| GPU PCI-slot 3 Thickness |
2.6 Slots / 53 mm | 2.08 in |
| Side 360 Radiator (L x W x H) |
413 x 134 x 60 mm | 16.25 x 5.27 x 2.36 in |
| Net Weight |
9.50 kg | 20.94 lbs |
| Gross Weight |
11.21 kg | 24.71 lbs |
| Warranty |
5 Years Limited (ดูเพิ่มเติม) |
| Scope of Delivery |
1x EX5-Max chassis, 1x HDD bracket (ติดตั้งมาแล้ว), 1x SSD bracket (ติดตั้งมาแล้ว) |
| Accessory Box |
6x Zip ties, 1x Stand-off removal tool, 1x ARGB mainboard adapter 80mm |
| Screws |
14x Mainboard/SSD screws, 4x Power supply/GPU bracket screws, 8x HDD screws, 1x Mainboard stand-off |
| GPU Bracket |
1x GPU bracket 241-308mm, 1x GPU bracket 275-358mm |
