Specifications
- Product NameELITE GOLD 1000
- ModelMPW-A001-AFAG
- ATX VersionATX 12V Ver. 3.1
- PFCActive PFC
- Input Voltage100-240V
- Input Current6 ~ 12A
- Input Frequency50-60Hz
- Dimensions (L x W x H)140 x 150 x 86 mm
- Fan Size120mm
- Fan BearingFDB
- Efficiency≥90% @ Typical Load
- 80 PLUS Rating80 PLUS Gold
- ErP 2014 Lot 3Yes
- Operating Temperature0-40°C
- Power Good Signal100 – 150 ms
- Hold Up Time≥16ms at 80% Load
- MTBF>100,000 hours @ 25℃ ambient
- ProtectionsUVP / OVP / OPP / OTP / SCP
- RegulatorycTUV us, CB, CE, FCC, BSMI, EAC, RCM, UKCA, RoHS2.0 , REACH
- ATX 24 Pin Connectorsx1 = 1 (600mm)
- EPS 4+4 Pin Connectorsx2 = 2 (700mm)
- SATA Connectorsx9 = 3 (500+100+100mm)
- Peripheral 4 Pin Connectorsx3 = 1 (500+100+100mm)
- PCI-e 6+2 Pin Connectorsx6 = 3 (550+120mm)
- 12+4 Pin Connectorsx1 = 1 (600mm)
- SeriesElite Series
- Form FactorATX
- Watts1000W
- ModularFully Modular
- 80 Plus EfficiencyGold
- Warranty10 Years
