Case PC เคสคอมพิวเตอร์, Computer (DIY) คอมพิวเตอร์ ประกอบ, Mid-Tower
Be Quiet PURE BASE 500DX WHITE
| Model : PURE BASE 500DX White Type : Mid Tower Side Panel Window : Yes Max GPU Legth : 369 mm With Power Supply : No |
1,990฿ 3,790฿
General data
| Model | Pure Base 500DX | White |
| PSU form factor | ATX PS/2 |
| Motherboard compatibility | ATX, M-ATX, Mini-ITX |
| Case size excl. stands (L x W x H), (mm) | 450 x 232 x 443 |
| Installation of motherboards with backplate | ✓ |
| Case size incl. stands (L x W x H), (mm) | 450 x 232 x 463 |
| Dimensions side panel window (L x W), (mm) | 400 x 431.3 |
| Color option | White |
| Weight (kg) | 7.8 |
| USB 2.0 | – |
| USB 3.0 | 1 |
| USB 3.1 Gen 2 Type C | 1 |
| HD Audio I/O | Mic + Audio |
| Expansion slots | 7 |
| Fan mounting locations | 6 |
| Qi charger / Quick Charging Option | – |
Infographics
Material
| Top cover | ABS |
| Side panel | Steel |
| Side panel window | Tempered Glass 4mm |
| Front panel | ABS |
| Stands | ABS |
Drive bay capacity
| 5.25 bays | – |
| 3.5 slots (max.) | 2 |
| 3.5 slots (scope of delivery) | 2 |
| 2.5 slots (max.) | 5 |
| 2.5 slots (scope of delivery) | 5 |
Pre-installed fans
| Fan @ front | 1x be quiet Pure Wings 2 | 140mm |
| Fan @ rear | 1x be quiet Pure Wings 2 | 140mm |
| Fan @ top | 1x be quiet Pure Wings 2 | 140mm |
| Dimensions (L x W x H), (mm) | 140 x 140 x 25 |
| Fan speed @ 100% PWM / 12V (rpm) | 900 |
| Noise level @ 100% PWM / 12V (dB(A)) | 17.10 |
| Airflow @ 100% PWM / 12V (CFM / m3/h) | 55.8 / 94.8 |
| Air Pressure @ 100% PWM / 12V (mm H2O) | 0.6 |
| Voltage range (V DC) | 12 |
| Input power (W) | 1.08 |
| Input current (A) | 0.09 |
| Connector | 3-Pin |
| Lifespan (h / 25°C) | 80,000 |
| Fan controller | – |
Optional fan installation
| Front (mm) | 1 x 140 | 3 x 120 |
| Top (mm) | 1 x 140 | 1 x 120 |
| Bottom (mm) | – |
| Side panel (mm) | – |
| PSU shroud | – |
Optional radiator installation
| Front (mm) | 120, 140, 240, 280, 360 |
| Top (mm) | 120, 140, 240 |
| Bottom (mm) | – |
| Rear (mm) | 120 / 140 |
Cooling
| Max.construction height of CPU cooler unit (mm) | 190 |
| Airflow channel | Front, Top, Rear |
Lighting
| RGB LED illumination | Front LED ARGB, Internal ARGB |
| LEDs synchronizable with RGB controller/motherboard | – |
| Expandable RGB controller | – |
PSU compatibility
| Maximum dimensions excl. bottom fan (mm) | 258 |
| Maximum dimensions incl. bottom fan (mm) | 225 |
Graphics card
| HDD cage (in height of graphics card) installed (mm) | 369 |
| HDD cage (in height of graphics card) removed (mm) | 369 |
Insulation and damping
| Top panel insulation mats | – |
| Front panel insulation mats | – |
| Side panel insulation mats | ✓ |
| Anti-vibration decoupled HDD | ✓ |
| Anti-vibration decoupled fan | – |
| Anti-vibration decoupled PSU | ✓ |
| Anti-vibration decoupled motherboard-tray | – |
Removeable dust filters
| Front | 1 |
| Bottom | 1 |
| Side panel | 1 |
Accessories
| Screw set (Drives/Motherboard) | ✓ |
| Rubber rail (pcs.) | – |
| Standoff (pcs.) | – |
| LCS bracket (pcs). | – |
| HDD slot cover (pcs.) | – |
| Upper fan bracket (pcs.) | – |
| HDD panel rubber grommet (pcs.) | – |
| SSD bracket for PSU shroud | – |
| LED strips (pcs.) | – |
| Cable ties (pcs.) | 6 | 4 (Velcro) |
| Cable tie holder (pcs.) | – |
Service
| Warranty (Years) | 3 |
| International hotline / free of charge | ✓ / DE, FR |
Logistics data, RRP
| Article number | BGW38 |
| EAN code | 4260052187944 |
| Certifications | CE, RoHS |
| Dimensions, package (L x W x H), (mm) | 510 x 285 x 494 |
| Gross weight, package (kg) | 8.49 |
| Pieces per packaging unit | 1 |
| RRP (€) | 99.90 |
